Product Description
- LFP(lithium iron phosphate) cell to ensure the highest safety
- Built-In BMS protects the cell such as Temperature, Current, Voltage, SoC
- SoH Extra long cycle life times with 6500 cycles with 80% DoD
- Compatible with most ofthe available lnverters
- Possibility of parallel connection with up to 4 pieces & Also series connection with up to 4 pieces
Product Specifications
| Model |
SWA-LAR-4S150 |
| General Information |
|
| Nominal Voltage |
12.8Vdc LFP |
| Nominal Capacity |
150Ah |
| Nominal Energy |
1920Wh |
| |
|
| Operating Parameters |
|
| Operating Voltage Range |
11.2V To 14.6V |
| Discharge Cut-Off Voltage |
10V |
| Max Discharging Current |
100A (Continuous) |
| Peak Discharging Current |
150A / 3s |
| Max Charging Voltage |
14.6V |
| Standard Charging Current |
30A (0.2C) |
| |
|
| Mechanical Specifications |
|
| Dimensions |
L488*W168*H240 mm |
| Weight |
≈16 Kg |
| Mounting Options |
Ground |
| |
|
| Environmental Specifications |
|
| Discharging Temperature |
-20℃ ~ 55℃ |
| Charging Temperature |
0℃ ~ 45℃ |
| Storage Temperature |
0℃ ~ 35℃ |
| Ingress Rating |
IP65 |
| Cycle Life |
≥6500 Cycles(0.2C,25℃@80% DoD) |
